- Part Number:1910
- Part Number Title:Occupational Safety and Health Standards
- Subpart:1910 Subpart G
- Subpart Title:Occupational Health and Environmental Control
- Standard Number:
- Title:Ventilation.
- GPO Source:
Abrasive blasting -
Definitions applicable to this paragraph -
Abrasive. A solid substance used in an abrasive blasting operation.
Abrasive-blasting respirator. A respirator constructed so that it covers the wearer's head, neck, and shoulders to protect the wearer from rebounding abrasive.
Blast cleaning barrel. A complete enclosure which rotates on an axis, or which has an internal moving tread to tumble the parts, in order to expose various surfaces of the parts to the action of an automatic blast spray.
Blast cleaning room. A complete enclosure in which blasting operations are performed and where the operator works inside of the room to operate the blasting nozzle and direct the flow of the abrasive material.
Blasting cabinet. An enclosure where the operator stands outside and operates the blasting nozzle through an opening or openings in the enclosure.
Clean air. Air of such purity that it will not cause harm or discomfort to an individual if it is inhaled for extended periods of time.
Dust collector. A device or combination of devices for separating dust from the air handled by an exhaust ventilation system.
Exhaust ventilation system. A system for removing contaminated air from a space, comprising two or more of the following elements
enclosure or hood,
duct work,
dust collecting equipment,
exhauster, and
discharge stack.
Particulate-filter respirator. An air purifying respirator, commonly referred to as a dust or a fume respirator, which removes most of the dust or fume from the air passing through the device.
Respirable dust. Airborne dust in sizes capable of passing through the upper respiratory system to reach the lower lung passages.
Rotary blast cleaning table. An enclosure where the pieces to be cleaned are positioned on a rotating table and are passed automatically through a series of blast sprays.
Abrasive blasting. The forcible application of an abrasive to a surface by pneumatic pressure, hydraulic pressure, or centrifugal force.
Dust hazards from abrasive blasting.
The concentration of respirable dust or fume in the breathing zone of the abrasive-blasting operator or any other worker shall be kept below the levels specified in § 1910.1000.
Organic abrasives which are combustible shall be used only in automatic systems. Where flammable or explosive dust mixtures may be present, the construction of the equipment, including the exhaust system and all electric wiring, shall conform to the requirements of American National Standard Installation of Blower and Exhaust Systems for Dust, Stock, and Vapor Removal or Conveying, Z33.1-1961 (NFPA 91-1961), which is incorporated by reference as specified in § 1910.6, and subpart S of this part. The blast nozzle shall be bonded and grounded to prevent the build up of static charges. Where flammable or explosive dust mixtures may be present, the abrasive blasting enclosure, the ducts, and the dust collector shall be constructed with loose panels or explosion venting areas, located on sides away from any occupied area, to provide for pressure relief in case of explosion, following the principles set forth in the National Fire Protection Association Explosion Venting Guide, NFPA 68-1954, which is incorporated by reference as specified in § 1910.6.
Blast-cleaning enclosures.
All air inlets and access openings shall be baffled or so arranged that by the combination of inward air flow and baffling the escape of abrasive or dust particules into an adjacent work area will be minimized and visible spurts of dust will not be observed.
[Reserved]
Exhaust ventilation systems.
The construction, installation, inspection, and maintenance of exhaust systems shall conform to the principles and requirements set forth in American National Standard Fundamentals Governing the Design and Operation of Local Exhaust Systems, Z9.2-1960, and ANSI Z33.1-1961, which is incorporated by reference as specified in § 1910.6.
Personal protective equipment.
Employers must use only respirators approved by the National Institute for Occupational Safety and Health (NIOSH) under 42 CFR part 84 to protect employees from dusts produced during abrasive-blasting operations.
Where concentrations of toxic dust dispersed by the abrasive blasting may exceed the limits set in § 1910.1000 and the nozzle and blast are not physically separated from the operator in an exhaust-ventilated enclosure.
Properly fitted particulate-filter respirators, commonly referred to as dust-filter respirators, may be used for short, intermittent, or occasional dust exposures such as cleanup, dumping of dust collectors, or unloading shipments of sand at a receiving point when it is not feasible to control the dust by enclosure, exhaust ventilation, or other means. The respirators used must be approved by NIOSH under 42 CFR part 84 for protection against the specific type of dust encountered.
Equipment for protection of the eyes and face shall be supplied to the operator when the respirator design does not provide such protection and to any other personnel working in the vicinity of abrasive blasting operations. This equipment shall conform to the requirements of § 1910.133.
Air supply and air compressors. Air for abrasive-blasting respirators must be free of harmful quantities of dusts, mists, or noxious gases, and must meet the requirements for supplied-air quality and use specified in 29 CFR 1910.134(i).
Operational procedures and general safety. Dust shall not be permitted to accumulate on the floor or on ledges outside of an abrasive-blasting enclosure, and dust spills shall be cleaned up promptly. Aisles and walkways shall be kept clear of steel shot or similar abrasive which may create a slipping hazard.
Scope. This paragraph (a) applies to all operations where an abrasive is forcibly applied to a surface by pneumatic or hydraulic pressure, or by centrifugal force. It does not apply to steam blasting, or steam cleaning, or hydraulic cleaning methods where work is done without the aid of abrasives.
Grinding, polishing, and buffing operations -
Definitions applicable to this paragraph -
Abrasive cutting-off wheels. Organic-bonded wheels, the thickness of which is not more than one forty-eighth of their diameter for those up to, and including, 20 inches in diameter, and not more than one-sixtieth of their diameter for those larger than 20 inches in diameter, used for a multitude of operations variously known as cutting, cutting off, grooving, slotting, coping, and jointing, and the like. The wheels may be “solid” consisting of organic-bonded abrasive material throughout, “steel centered” consisting of a steel disc with a rim of organic-bonded material moulded around the periphery, or of the “inserted tooth” type consisting of a steel disc with organic-bonded abrasive teeth or inserts mechanically secured around the periphery.
Belts. All power-driven, flexible, coated bands used for grinding, polishing, or buffing purposes.
Branch pipe. The part of an exhaust system piping that is connected directly to the hood or enclosure.
Cradle. A movable fixture, upon which the part to be ground or polished is placed.
Disc wheels. All power-driven rotatable discs faced with abrasive materials, artificial or natural, and used for grinding or polishing on the side of the assembled disc.
Entry loss. The loss in static pressure caused by air flowing into a duct or hood. It is usually expressed in inches of water gauge.
Exhaust system. A system consisting of branch pipes connected to hoods or enclosures, one or more header pipes, an exhaust fan, means for separating solid contaminants from the air flowing in the system, and a discharge stack to outside.
Grinding wheels. All power-driven rotatable grinding or abrasive wheels, except disc wheels as defined in this standard, consisting of abrasive particles held together by artificial or natural bonds and used for peripheral grinding.
Header pipe (main pipe). A pipe into which one or more branch pipes enter and which connects such branch pipes to the remainder of the exhaust system.
Hoods and enclosures. The partial or complete enclosure around the wheel or disc through which air enters an exhaust system during operation.
Horizontal double-spindle disc grinder. A grinding machine carrying two power-driven, rotatable, coaxial, horizontal spindles upon the inside ends of which are mounted abrasive disc wheels used for grinding two surfaces simultaneously.
Horizontal single-spindle disc grinder. A grinding machine carrying an abrasive disc wheel upon one or both ends of a power-driven, rotatable single horizontal spindle.
Polishing and buffing wheels. All power-driven rotatable wheels composed all or in part of textile fabrics, wood, felt, leather, paper, and may be coated with abrasives on the periphery of the wheel for purposes of polishing, buffing, and light grinding.
Portable grinder. Any power-driven rotatable grinding, polishing, or buffing wheel mounted in such manner that it may be manually manipulated.
Scratch brush wheels. All power-driven rotatable wheels made from wire or bristles, and used for scratch cleaning and brushing purposes.
Swing-frame grinder. Any power-driven rotatable grinding, polishing, or buffing wheel mounted in such a manner that the wheel with its supporting framework can be manipulated over stationary objects.
Velocity pressure (vp). The kinetic pressure in the direction of flow necessary to cause a fluid at rest to flow at a given velocity. It is usually expressed in inches of water gauge.
Vertical spindle disc grinder. A grinding machine having a vertical, rotatable power-driven spindle carrying a horizontal abrasive disc wheel.
Application. Wherever dry grinding, dry polishing or buffing is performed, and employee exposure, without regard to the use of respirators, exceeds the permissible exposure limits prescribed in § 1910.1000 or other sections of this part, a local exhaust ventilation system shall be provided and used to maintain employee exposures within the prescribed limits.
Hood and branch pipe requirements.
Grinding wheels on floor stands, pedestals, benches, and special-purpose grinding machines and abrasive cutting-off wheels shall have not less than the minimum exhaust volumes shown in Table G-4 with a recommended minimum duct velocity of 4,500 feet per minute in the branch and 3,500 feet per minute in the main. The entry losses from all hoods except the vertical-spindle disc grinder hood, shall equal 0.65 velocity pressure for a straight takeoff and 0.45 velocity pressure for a tapered takeoff. The entry loss for the vertical-spindle disc grinder hood is shown in figure G-1 (following § 1910.94(b)).
TABLE G-4 - GRINDING AND ABRASIVE CUTTING-OFF WHEELS
Wheel diameter (inches) | Wheel width (inches) | Minimum exhaust volume (feet3/min.) |
---|---|---|
To 9 | 1½ | 220 |
Over 9 to 16 | 2 | 390 |
Over 16 to 19 | 3 | 500 |
Over 19 to 24 | 4 | 610 |
Over 24 to 30 | 5 | 880 |
Over 30 to 36 | 6 | 1,200 |
For any wheel wider than wheel diameters shown in Table G-4, increase the exhaust volume by the ratio of the new width to the width shown.
Example:
If wheel width = 4½ inches, then 4.5 ÷ 4 × 610 = 686 (rounded to 690).
Scratch-brush wheels and all buffing and polishing wheels mounted on floor stands, pedestals, benches, or special-purpose machines shall have not less than the minimum exhaust volume shown in Table G-5.
Table G-5 - Buffing and Polishing Wheels
Wheel diameter (inches) | Wheel width (inches) | Minimum exhaust volume (feet3/min.) |
---|---|---|
To 9 | 2 | 300 |
Over 9 to 16 | 3 | 500 |
Over 16 to 19 | 4 | 610 |
Over 19 to 24 | 5 | 740 |
Over 24 to 30 | 6 | 1,040 |
Over 30 to 36 | 6 | 1,200 |
Grinding wheels or discs for horizontal single-spindle disc grinders shall be hooded to collect the dust or dirt generated by the grinding operation and the hoods shall be connected to branch pipes having exhaust volumes as shown in Table G-6.
Table G-6 - Horizontal Single-Spindle Disc Grinder
Disc diameter (inches) | Exhaust volume (ft.3/min.) |
---|---|
Up to 12 | 220 |
Over 12 to 19 | 390 |
Over 19 to 30 | 610 |
Over 30 to 36 | 880 |
Grinding wheels or discs for horizontal double-spindle disc grinders shall have a hood enclosing the grinding chamber and the hood shall be connected to one or more branch pipes having exhaust volumes as shown in Table G-7.
Table G-7 - Horizontal Double-Spindle Disc Grinder
Disc diameter (inches) | Exhaust volume (ft.3/min.) |
---|---|
Up to 19 | 610 |
Over 19 to 25 | 880 |
Over 25 to 30 | 1,200 |
Over 30 to 53 | 1,770 |
Over 53 to 72 | 6,280 |
Grinding wheels or discs for vertical single-spindle disc grinders shall be encircled with hoods to remove the dust generated in the operation. The hoods shall be connected to one or more branch pipes having exhaust volumes as shown in Table G-8.
Table G-8 - Vertical Spindle Disc Grinder
Disc diameter (inches) | One-half or more of disc covered | Disc not covered | ||
---|---|---|---|---|
Number1 | Exhaust foot3/min.) | Number1 | Exhaust foot3/min. | |
Up to 20 | 1 | 500 | 1 | 780 |
Over 20 to 30 | 2 | 780 | 2 | 1,480 |
Over 30 to 53 | 2 | 1,770 | 4 | 3,530 |
Over 53 to 72 | 2 | 3,140 | 5 | 6,010 |
1 Number of exhaust outlets around periphery of hood, or equal distribution provided by other means.
Grinding and polishing belts shall be provided with hoods to remove dust and dirt generated in the operations and the hoods shall be connected to branch pipes having exhaust volumes as shown in Table G-9.
Table G-9 - Grinding and Polishing Belts
Belts width (inches) | Exhaust volume (ft.3/min.) |
---|---|
Up to 3 | 220 |
Over 3 to 5 | 300 |
Over 5 to 7 | 390 |
Over 7 to 9 | 500 |
Over 9 to 11 | 610 |
Over 11 to 13 | 740 |
Exhaust systems.
Hood and enclosure design.
Grinding and polishing belt hoods shall be constructed as close to the operation as possible. The hood should extend almost to the belt, and 1-inch wide openings should be provided on either side. Figure G-8 shows a typical hood for a belt operation.

Dia D. inches | Exhaust E | Volume Exhausted at 4,500 ft/min ft3/min | Note | ||
---|---|---|---|---|---|
Min. | Max. | No Pipes | Dia. | ||
20 | 1 | 4¼ | 500 | When one-half or more of the disc can be hooded, use exhaust ducts as shown at the left. | |
Over 20 | 30 | 2 | 4 | 780 | |
Over 30 | 72 | 2 | 6 | 1,770 | |
Over 53 | 72 | 2 | 8 | 3,140 | |
20 | 2 | 4 | 780 | When no hood can be used over disc, use exhaust ducts as shown at left. | |
Over 20 | 20 | 2 | 4 | 780 | |
Over 30 | 30 | 2 | 5½ | 1,480 | |
Over 53 | 53 | 4 | 6 | 3,530 | |
72 | 5 | 7 | 6,010 |
Entry loss = 1.0 slot velocity pressure + 0.5 branch velocity pressure.
Minimum slot velocity = 2,000 ft/min - ½-inch slot width.

Wheel dimension, inches | Exhaust outlet, inches E | Volume of air at 4,500 ft/min | ||
---|---|---|---|---|
Diameter | Width, Max | |||
Min=d | Max=D | |||
9 | 1½ | 3 | 220 | |
Over 9 | 16 | 2 | 4 | 390 |
Over 16 | 19 | 3 | 4½ | 500 |
Over 19 | 24 | 4 | 5 | 610 |
Over 24 | 30 | 5 | 6 | 880 |
Over 30 | 36 | 6 | 7 | 1,200 |
Entry loss = 0.45 velocity pressure for tapered takeoff 0.65 velocity pressure for straight takeoff.


Standard Buffing and Polishing Hood
Wheel dimension, inches | Exhaust outlet, inches E | Volume of air at 4,500 ft/min | ||
---|---|---|---|---|
Diameter | Width, Max | |||
Min=d | Max=D | |||
9 | 2 | 3½ | 300 | |
Over 9 | 16 | 3 | 4 | 500 |
Over 16 | 19 | 4 | 5 | 610 |
Over 19 | 24 | 5 | 5½ | 740 |
Over 24 | 30 | 6 | 6½ | 1.040 |
Over 30 | 36 | 6 | 7 | 1.200 |
Entry loss = 0.15 velocity pressure for tapered takeoff; 0.65 velocity pressure for straight takeoff.


Dia D, inches | Exhaust E, dia. inches | Volume exhausted at 4,500 ft/min ft3/min | |
---|---|---|---|
Min. | Max. | ||
12 | 3 | 220 | |
Over 12 | 19 | 4 | 390 |
Over 19 | 30 | 5 | 610 |
Over 30 | 36 | 6 | 880 |
Note: If grinding wheels are used for disc grinding purposes, hoods must conform to structural strength and materials as described in 9.1.
Entry loss = 0.45 velocity pressure for tapered takeoff.

Disc dia. inches | Exhaust E | Volume exhaust at 4,500 ft/min. ft3/min | Note | ||
---|---|---|---|---|---|
Min. | Max. | No Pipes | Dia. | ||
19 | 1 | 5 | 610 | ||
Over 19 | 25 | 1 | 6 | 880 | When width “W” permits, exhaust ducts should be as near heaviest grinding as possible. |
Over 25 | 30 | 1 | 7 | 1,200 | |
Over 30 | 53 | 2 | 6 | 1,770 | |
Over 53 | 72 | 4 | 8 | 6,280 |
Entry loss = 0.45 velocity pressure for tapered takeoff.

Belt width W. Inches | Exhaust volume. ft.1/min |
---|---|
Up to 3 | 220 |
3 to 5 | 300 |
5 to 7 | 390 |
7 to 9 | 500 |
9 to 11 | 610 |
11 to 13 | 740 |
Minimum duct velocity = 4,500 ft/min branch, 3,500 ft/min main.
Entry loss = 0.45 velocity pressure for tapered takeoff; 0.65 velocity pressure for straight takeoff.
Scope. This paragraph (b), prescribes the use of exhaust hood enclosures and systems in removing dust, dirt, fumes, and gases generated through the grinding, polishing, or buffing of ferrous and nonferrous metals.
Spray finishing operations -
Definitions applicable to this paragraph -
Spray-finishing operations. Spray-finishing operations are employment of methods wherein organic or inorganic materials are utilized in dispersed form for deposit on surfaces to be coated, treated, or cleaned. Such methods of deposit may involve either automatic, manual, or electrostatic deposition but do not include metal spraying or metallizing, dipping, flow coating, roller coating, tumbling, centrifuging, or spray washing and degreasing as conducted in self-contained washing and degreasing machines or systems.
Spray booth. Spray booths are defined and described in § 1910.107(a).
Spray room. A spray room is a room in which spray-finishing operations not conducted in a spray booth are performed separately from other areas.
Minimum maintained velocity. Minimum maintained velocity is the velocity of air movement which must be maintained in order to meet minimum specified requirements for health and safety.
Location and application. Spray booths or spray rooms are to be used to enclose or confine all operations. Spray-finishing operations shall be located as provided in sections 201 through 206 of the Standard for Spray Finishing Using Flammable and Combustible Materials, NFPA No. 33-1969.
Design and construction of spray booths.
Unobstructed walkways shall not be less than 6½ feet high and shall be maintained clear of obstruction from any work location in the booth to a booth exit or open booth front. In booths where the open front is the only exit, such exits shall be not less than 3 feet wide. In booths having multiple exits, such exits shall not be less than 2 feet wide, provided that the maximum distance from the work location to the exit is 25 feet or less. Where booth exits are provided with doors, such doors shall open outward from the booth.
Design and construction of spray rooms.
Ventilation.
[Reserved]
Exhaust ductwork shall be sized in accordance with good design practice which shall include consideration of fan capacity, length of duct, number of turns and elbows, variation in size, volume, and character of materials being exhausted. See American National Standard Z9.2-1960 for further details and explanation concerning elements of design.
Velocity and air flow requirements.
Except where a spray booth has an adequate air replacement system, the velocity of air into all openings of a spray booth shall be not less than that specified in Table G-10 for the operating conditions specified. An adequate air replacement system is one which introduces replacement air upstream or above the object being sprayed and is so designed that the velocity of air in the booth cross section is not less than that specified in Table G-10 when measured upstream or above the object being sprayed.
Table G-10 - Minimum Maintained Velocities Into Spray Booths
Operating conditions for objects completely inside booth | Crossdraft, f.p.m. | Airflow velocities, f.p.m. | |
---|---|---|---|
Design | Range | ||
Electrostatic and automatic airless operation contained in booth without operator | Negligible | 50 large booth | 50-75 |
100 small booth | 75-125 | ||
Air-operated guns, manual or automatic | Up to 50 | 100 large booth | 75-125 |
150 small booth | 125-175 | ||
Air-operated guns, manual or automatic | Up to 100 | 150 large booth | 125-175 |
200 small booth | 150-250 |
Notes:
(1) Attention is invited to the fact that the effectiveness of the spray booth is dependent upon the relationship of the depth of the booth to its height and width.
(2) Crossdrafts can be eliminated through proper design and such design should be sought. Crossdrafts in excess of 100fpm (feet per minute) should not be permitted.
(3) Excessive air pressures result in loss of both efficiency and material waste in addition to creating a backlash that may carry overspray and fumes into adjacent work areas.
(4) Booths should be designed with velocities shown in the column headed “Design.” However, booths operating with velocities shown in the column headed “Range” are in compliance with this standard.
In addition to the requirements in paragraph (c)(6)(i) of this section the total air volume exhausted through a spray booth shall be such as to dilute solvent vapor to at least 25 percent of the lower explosive limit of the solvent being sprayed. An example of the method of calculating this volume is given below.
Example: To determine the lower explosive limits of the most common solvents used in spray finishing, see Table G-11. Column 1 gives the number of cubic feet of vapor per gallon of solvent and column 2 gives the lower explosive limit (LEL) in percentage by volume of air. Note that the quantity of solvent will be diminished by the quantity of solids and nonflammables contained in the finish.
To determine the volume of air in cubic feet necessary to dilute the vapor from 1 gallon of solvent to 25 percent of the lower explosive limit, apply the following formula:
Dilution volume required per gallon of solvent = 4 (100−LEL) (cubic feet of vapor per gallon) ÷ LEL
Using toluene as the solvent.
(1) LEL of toluene from Table G-11, column 2, is 1.4 percent.
(2) Cubic feet of vapor per gallon from Table G-11, column 1, is 30.4 cubic feet per gallon.
(3) Dilution volume required=
4 (100−1.4) 30.4 ÷ 1.4 = 8,564 cubic feet.
(4) To convert to cubic feet per minute of required ventilation, multiply the dilution volume required per gallon of solvent by the number of gallons of solvent evaporated per minute.
Table G-11 - Lower Explosive Limit of Some Commonly Used Solvents
Solvent | Cubic feet per gallon of vapor of liquid at 70 °F. | Lower explosive limit in percent by volume of air at 70 °F |
---|---|---|
Column 1 | Column 2 | |
Acetone | 44.0 | 2.6 |
Amyl Acetate (iso) | 21.6 | 1 1.0 |
Amyl Alcohol (n) | 29.6 | 1.2 |
Amyl Alcohol (iso) | 29.6 | 1.2 |
Benzene | 36.8 | 1 1.4 |
Butyl Acetate (n) | 24.8 | 1.7 |
Butyl Alcohol (n) | 35.2 | 1.4 |
Butyl Cellosolve | 24.8 | 1.1 |
Cellosolve | 33.6 | 1.8 |
Cellosolve Acetate | 23.2 | 1.7 |
Cyclohexanone | 31.2 | 1 1.1 |
1,1 Dichloroethylene | 42.4 | 5.9 |
1,2 Dichloroethylene | 42.4 | 9.7 |
Ethyl Acetate | 32.8 | 2.5 |
Ethyl Alcohol | 55.2 | 4.3 |
Ethyl Lactate | 28.0 | 1 1.5 |
Methyl Acetate | 40.0 | 3.1 |
Methyl Alcohol | 80.8 | 7.3 |
Methyl Cellosolve | 40.8 | 2.5 |
Methyl Ethyl Ketone | 36.0 | 1.8 |
Methyl n-Propyl Ketone | 30.4 | 1.5 |
Naphtha (VM&P) (76° Naphtha) | 22.4 | 0.9 |
Naphtha (100 °Flash) Safety Solvent - Stoddard Solvent | 23.2 | 1.0 |
Propyl Acetate (n) | 27.2 | 2.8 |
Propyl Acetate (iso) | 28.0 | 1.1 |
Propyl Alcohol (n) | 44.8 | 2.1 |
Propyl Alcohol (iso) | 44.0 | 2.0 |
Toluene | 30.4 | 1.4 |
Turpentine | 20.8 | 0.8 |
Xylene (o) | 26.4 | 1.0 |
1 At 212 °F.
When an operator is in a booth downstream from the object being sprayed, an air-supplied respirator or other type of respirator must be used by employees that has been approved by NIOSH under 42 CFR part 84 for the material being sprayed.
Make-up air.
Means for heating make-up air to any spray booth or room, before or at the time spraying is normally performed, shall be provided in all places where the outdoor temperature may be expected to remain below 55 °F. for appreciable periods of time during the operation of the booth except where adequate and safe means of radiant heating for all operating personnel affected is provided. The replacement air during the heating seasons shall be maintained at not less than 65 °F. at the point of entry into the spray booth or spray room. When otherwise unheated make-up air would be at a temperature of more than 10 °F. below room temperature, its temperature shall be regulated as provided in section 3.6.3 of ANSI Z9.2-1960.
As an alternative to an air replacement system complying with the preceding section, general heating of the building in which the spray room or booth is located may be employed provided that all occupied parts of the building are maintained at not less than 65 °F. when the exhaust system is in operation or the general heating system supplemented by other sources of heat may be employed to meet this requirement.
Scope. Spray booths or spray rooms are to be used to enclose or confine all spray finishing operations covered by this paragraph (c). This paragraph does not apply to the spraying of the exteriors of buildings, fixed tanks, or similar structures, nor to small portable spraying apparatus not used repeatedly in the same location.
[39 FR 23502, June 27, 1974, as amended at 40 FR 23073, May 28, 1975; 40 FR 24522, June 9, 1975; 43 FR 49746, Oct. 24, 1978; 49 FR 5322, Feb. 10, 1984; 55 FR 32015, Aug. 6, 1990; 58 FR 35308, June 30, 1993; 61 FR 9227, March 7, 1996; 63 FR 1152, Jan. 8, 1998; 64 FR 13909, March 23, 1999; 72 FR 71069, Dec. 14, 2007; 74 FR 46356, Sept. 9, 2009]
